Access Control
HST-P Proximity Card
tk4100 chip proximity card with number,0.8mm thickness
HST-RE01
Indoor remote control
Power Supply: 12V DC
2 Relay Output
HST-RE02
Outdoor remote control
Power Supply: 12V DC
2 Relay Output
HST-RP-09W Multi-Prox reader
- 125KHZ RF reader with Wigand output HST
- Maximum read range 150mm (6.00 in)•Modulation: ASK at 125 kHz
- Supports Multi Wigand Output:
- AWID: Follow card, up to 58bits
- EM, 2308: Option-W26/34
- HID: Follow card, W26/27/34/35/37 and so on
- KK: Follow card, W34/50 bits
- Operating Humidity: 0 to 95%
- LED Control Input: Dry Contact, Normally Open
- Buzzer Control Input: Dry Contact, Normally Open
HST-RU-09W
• 13.6MHZ Mifare RF reader with Wigand output HST
• Maximum read range 50mm (2.00in)
• Modulation: ASK at 13.56MHz
• Compatible cards: Mifare S50, S70, KK1208M1 CPU cards
• ISO14443A
• Operating Humidity: 0 to 95%
• LED Control Input: Dry Contact, Normally Open
• Buzzer Control Input: Dry Contact, Normally Open
• Tamper Output: Open collector, active low 32mA maxsink current.Optical Technology
HST-SC-01 Slave Controller
- Reader interface: 2Compatible with all Wiegand26-72 inputs,
- Communication interface: RS485 (with overcurrent, over voltage)
- Number of control doors: 1Electric lock control: 1 (withover current protection 3A)
- Door open button: 1way (dry node input)
- Door sensor input: 1 (dry node input)
- Auxiliary input: 2 (dry node input)
- Auxiliary output: 1 (with over current protection 3A)
- Networking distance: 1200M
HST-TLB
Non touch/Touch free Exit Sensor (Diffused Detection)
NO NC COM relay output
Size: 115L×70W(mm) With HST logo
HST-TLB-R
Non touch/Touch free Exit Sensor (Diffused Detection)
Remote Control Size: 115L×70W(mm) With HST logo
ID Tag-PL
HST logo epoxy tag with string ID 125khz,Size: 50 * 30mm
ID Tag-PR
HST logo epoxy tag with string ID 125khz,Diameter Size: 35mm
